Cluster
|
Processor
|
Nodes
|
Cores
|
- DWF Performance
- (MFlops/node)
|
- asqtad Performance
- (MFlops/node)
|
qcd
|
2.8GHz Single CPU Single Core P4E
|
127
|
127
|
1,400
|
1,017
|
pion
|
3.2GHz Single CPU Single Core Pentium 640
|
486
|
486
|
1,729
|
1,594
|
kaon
|
2.0GHz Dual CPU Dual Core Opteron
|
600
|
2,400
|
4,703
|
3,832
|
jpsi
|
2.1GHz Dual CPU Quad Core Opteron
|
856
|
6,848
|
10,061
|
9,563
|
ds
|
2GHz Quad CPU Eight Core Opteron
|
420
|
13,440
|
51,520
|
50,547
|
bc
|
2.8GHz Quad CPU Eight Core Opteron
|
224
|
7,168
|
57,408
|
56,224
|
pi0
|
2.6GHz Dual CPU Eight Core Intel
|
314
|
5,024
|
78,310
|
61,490
|
LQ1
|
2.5GHz Dual CPU 20 Core Intel
|
183
|
7,320
|
370k
|
280k
|
|
The table above shows the measured performance of DWF and asqtad inverters on all the Fermilab LQCD clusters. For qcd and pion, the asqtad numbers were taken on 64-node runs, 14^4 local lattice per node, and the DWF numbers were taken on 64-node runs using Ls=16, averaging the performance of 32x8x8x8 and 32x8x8x12 local lattice runs together. The DWF and asqtad performance figures for kaon use 128-process (32-node) runs, with 4 processes per node, one process per core. The DWF and asqtad performance figures for jpsi use 128-process (16-node) runs, with 8 processes per node, one process per core. The DWF and asqtad performance figures for ds and bc use 128-process (4-node) runs, with 32 processes per node, one process per core.
|
Details
|
Visual
|
qcd: 120-node cluster (decommissioned April 2010 ) with single-socket 2.8 GHz Pentium 4 processors and a Myrinet fabric.
|
|
pion: 486-node cluster (decommissioned April 2010 ) with single-socket 3.2 GHz Pentium 640 processors and SDR Infiniband fabric.
|
|
kaon: 600-node cluster (decommissioned August 2013 ) with dual-socket dual-core Opteron 270 (2.0 GHz) processors and a DDR Mellanox Infiniband fabric.
|
|
jPsi: 856-node cluster (decommissioned May 19 2014 ) with dual-socket quad-core Opteron 2352 (2.1 GHz) processors and a DDR Mellanox Infiniband fabric.
|
|
ds: 420-node cluster (224 nodes decommissioned August 2016, 196 nodes decommissioned April 2020 ) with quad-socket eight-core Opteron 6128 (2.0 GHz) processors and a QDR Mellanox Infiniband fabric.
|
|
dsg: 76-node cluster (decommissioned April 2020 ) with dual-socket four-core Intel Xeon E5630 processors, two NVIDIA Tesla M2050 GPUs per node and a QDR Mellanox Infiniband fabric.
|
|
bc: 224-node cluster (decommissioned April 2020 ) with quad-socket eight-core Opteron 6320 (2.8 GHz) processors and a QDR Mellanox Infiniband fabric.
|
|
π: 314-node cluster (decommissioned April 2020 ) with dual-socket eight-core Intel E5-2650v2 "Ivy Bridge" (2.6 GHz) processors and a QDR Mellanox Infiniband fabric.
|
|
π0g: 32-node cluster (decommissioned April 2020 ) with dual-socket eight-core Intel E5-2650v2 "Ivy Bridge" (2.6 GHz) processors, four NVidia Tesla K40m GPUs per node and a QDR Mellanox Infiniband fabric.
|
|
LQ1:183-node cluster with dual-socket 20-core Intel 6248 "Cascade Lake" (2.5 GHz) processors and an EDR Omni-Path fabric.
|
|
|
